Model No | Feeding Hopper A x B (mm) | Blade | Mesh Hole | Motor | Output (kg/hr) | Machine Dimension L x W x H (mm) | Weight (Kg) | |
---|---|---|---|---|---|---|---|---|
Fix | Rotary | (mm) | KW / HP | |||||
HPGRI08 | 210 X 185 | 2 | 6 | 8 | 2.2 / 3 | Upto 45 | 700 X 450 X 1000 | 130 |
HPGRI12 | 310 X 210 | 2 | 9 | 8 | 3.7 / 5 | Upto 60 | 1000 X 750 X 1300 | 300 |
HPGRI16 | 410 X 365 | 2 | 12 | 10 | 7.5 / 10 | Upto 125 | 1250 X 800 X 1650 | 470 |
HPGRI18 | 450 X 365 | 2 | 9 | 12 | 11.5 / 15 | Upto 150 | 1250 X 850 X 1650 | 515 |
HPGRI20 | 510 X 365 | 4 | 15 | 12 | 11.5 / 15 | Upto 180 | 1250 X 900 X 1650 | 535 |
HPGRI24 | 610 X 570 | 4 | 6 | 16 | 22.5 / 30 | Upto 300 | 2100 X 1300 X 2000 | 1280 |
HPGRI28 | 715 X 570 | 4 | 6 | 18 | 22.5 / 30 | Upto 350 | 2250 X 1500 X 2200 | 1500 |
HPGRI32 | 815 X 715 | 4 | 6 | 20 | 30 / 40 | Upto 500 | 2300 X 1500 X 2300 | 1900 |
HPGRI36 | 915 X 715 | 4 | 6 | 25 | 37 / 50 | Upto 600 | 2400 X 1650 X 2300 | 2000 |
HPGRI40 | 1020 X 715 | 4 | 6 | 25 | 37 / 50 | Upto 700 | 2400 X 1650 X 2300 | 2200 |
- Designed as a multifunctional granulator to grind runners & small articles.
- Can be used as low-noise central granulators for small throughput requirements as well.
- It has good Grind quality with a staggered rotor system.
- Low power consumption saving power.
- Mounted with high-quality alloy steel blades to grind all grades of plastics.
- Precisely designed
- Robust construction
- very wide range that gives solutions to all types of granulation needs.
- Suitable for offline and online applications with the blow, injection, and extrusion machines.
- Options like different cutter house widths, rotor configurations, hopper designs, rotor speeds, and conveying systems are available.
- Clean double scissors cutting action and constant cutting circle, produce granules of uniform size with minimum dust even with tough plastic materials.
- Less energy is required to granulate due to true double-scissor cutting action.
- The ergonomic design of each model for easy accessibility in case of cleaning and maintenance.
